Pile Cage Welding Machine HGZ Series

Introduction of Pile Cage Welding Machine

Reinforcement cage is used more and more in the construction projects, the traditional manual made steel cage is a waste of time and labor, low efficiency, there is an urgent need for automatic or semi-automatic reinforcement cage equipment. It can be widely used in steel processing plants as well as pile construction and construction units. Dostar HGZ series cage molding machine is high accuracy designed and manufactured. It's widely used for drilling pile reinforcement cage processing.

  • Concrete pile cage welding machine
  • Concrete pile cage welding machine
  • Concrete pile cage welding machine
  • Concrete pile cage welding machine
  • Concrete pile cage welding machine
  • Pile Cage Welding Machine HGZ Series
Desciption

Features of Pile Cage Welding Machine

1. Wire Cage Welding Machine has advanced technology is introduced from Europe, lots of parts have patent for invention, the high efficiency also high endurance and humane designings are safe and reliable;

2. Wire Cage Welding Machine is made of high precision of PLC control, LCD display is easy for operating, have mighty graphics library, it is able to communicate with management software;

3. Electric-Resistance-Welded in use, energy conservation and consumption reduction;

4. Rebar cages welding machine: cage diameter 300-4000mm.



Technical Parameters


Model

HGZ300-1200

HGZ800-2400

HGZ1350-3000

HGZ1800-3600

HGZ2800-4000

Cage Dia.(mm)

Ф300- Ф 1200

Ф 800- Ф 2400

Ф 1350- Ф 3000

Ф 1800- Ф 3600

Ф 2800- Ф 4000

Cage Length(mm)

2000-4000

2000-4000

2500

2500

2500

Longitudinal Bar(mm)

Max.12

Max.24

Max.32

Max.48

Max.66

Longitudinal Bar Dia.(mm)

4-6

4-10

6-12

6-16

6-16

Bar Gap(mm)

20-150

20-150

20-100

20-100

20-100

Welding Speed

30R/Min.

12 R/Min.

8 R/Min.

6 R/Min.

5 R/Min.

Welding Type

Plate-type

Plate-type

Wheel-type

Wheel-type

Wheel-type

Power

Intermediate Frequency Inverter

Intermediate Frequency Inverter

Intermediate Frequency Inverter

Intermediate Frequency Inverter

Intermediate Frequency Inverter
